DC Motor Speed Controller 5a

Description:
Reliable and suitable for a wide range of uses, High conversion efficiency, simple regulating operation.
High energy efficiency, low power consumption, energy conservation and durability, Can be used for electronic enthusiasts DIY production, maintenance.
On-board power indicator and the potentiometer has power switch function ideal for controlling motor speed or LED light brightness.
On-board rotary potentiometer stepless regulate the speed with 1%-100% PWM duty cycle.
The motor speed controller can easily provide a continuous current of 5A to your DC motor or other DC load; Default disconnection of short circuit point ,it is Applicable to 5-35V input voltage.

New and high quality
Potentiometer type: synthetic carbon film potentiometer
Working voltage: dc4.5v-35v
Output current: 0-5A
Output power: 90W (maximum)
Quiescent current: 7U a (standby state)
PWM duty cycle: 1%-100%
PWM frequency: 20KHz
Size: length 30mm x width 26mm (excluding handle) x height 14mm
Color: as shown in the figure
Package includes: 1pc
Note:
Please refer to the measurement. Tiny measuring error is allowable in normal range.
There might be a little color difference due to the monitor, camera or other factors, please refer to the physical item.
