74LS76 Dual JK Flip-Flop dip IC

74LS76 Dual JK Flip-Flop with Preset and Clear – DIP IC

The 74LS76 is a Dual JK Flip-Flop IC with Preset and Clear inputs, widely used in sequential logic circuits, counters, shift registers, and memory storage applications. It is part of the 74LS TTL logic family, offering low power consumption and fast switching speeds.

🔧 Specifications:

• IC Number: 74LS76 / SN74LS76N

• Logic Family: 74LS (Low Power Schottky TTL)

• Function: Dual JK Flip-Flop with Preset and Clear

• Package: DIP (Dual Inline Package)

• Voltage Supply (Vcc): 4.75V – 5.25V (typical 5V)

• Output Current: ±8mA

• Pin Count: 16

✅ Features:

• Dual JK Flip-Flop with independent inputs

• Asynchronous Preset (PR) and Clear (CLR)

• Fast switching with LS-TTL technology

• Compatible with TTL/CMOS logic levels

📦 Applications:

• Sequential logic design

• Frequency dividers and counters

• Data storage and registers

• Timing and control circuits

• Educational and DIY digital electronics
