The TTL/MSI SN54/74LS151 is a high speed 8-input Digital Multiplexer. It provides, in one package, the ability to select one bit of data from up to eight sources. The LS151 can be used as a universal function generator to generate any logic function of four variables. Both assertion and negation outputs are provided. • Schottky Process for High Speed • Multifunction Capability • On-Chip Select Logic Decoding • Fully Buffered Complementary Outputs • Input Clamp Diodes Limit High Speed Termination Effect
74LS151 Features & Specifications
- Technology Family: LS
- Rating: Catalog
- Function: multiplexer
- Supply voltage: 5.25V
- Frequency at nominal voltage: 35 MHz
- Typical propagation delay: 21nS
- Low power consumption: 30mW
- ESD protection
- Channels (#): 1
- Bits (#): 16
- Digital input leakage (Max) (uA): 5
- Operating temperature: 0ºC to 70ºC
- ESD CDM (kV): 0.75
- ESD HBM (kV): 2
- Balanced propagation delays
- Designed specifically for high speed
- IOL (Max): 16mA
- IOH (Max): -0.8mA
- Configuration: 8:1
- Product type: Standard
Applications
- It is used to increase the efficiency of the communication system
